주파수
범위
(GHz) |
제품명 |
VSWR |
삽입
손실
(dB) |
격리도
(dB) |
진폭
편차
(dB) |
위상
편차
(deg.) |
허용
입력
(watts) |
크기
(mm)
(WxDXH) |
| 입력 |
출력 |
| 0.5~1.0 |
2PD0510S |
1.30 |
1.20 |
0.5 |
22 |
0.2 |
2.0 |
10 |
55x42x10 |
| 0.5~2.0 |
2PD0520S |
1.20 |
1.15 |
0.5 |
24 |
0.2 |
2.0 |
10 |
55x42x10 |
| 0.5~2.5 |
2PD0525S |
1.25 |
1.20 |
0.6 |
23 |
0.2 |
2.0 |
10 |
55x42x10 |
| 0.5~6.0 |
2PD0560S |
1.30 |
1.25 |
0.5 |
22 |
0.2 |
2.0 |
10 |
55x42x10 |
| 0.5~12.0 |
2PD05120S |
1.45 |
1.40 |
0.8 |
20 |
0.2 |
0.5 |
10 |
55x42x10 |
| 0.5~18.0 |
2PD05180S |
1.65 |
1.60 |
1.0 |
18 |
0.2 |
2.0 |
10 |
55x42x10 |
| 0.7~2.0 |
2PD0720S |
1.20 |
1.15 |
0.5 |
22 |
0.1 |
1.5 |
10 |
55x42x10 |
| 0.8~1.0 |
2PD0810S |
1.15 |
1.10 |
0.2 |
25 |
0.1 |
1.5 |
10 |
55x42x10 |
| 0.8~2.5 |
2PD0825S |
1.30 |
1.25 |
0.6 |
23 |
0.2 |
2.0 |
10 |
55x42x10 |
| 2.0~6.0 |
2PD2060S |
1.25 |
1.20 |
0.5 |
22 |
0.2 |
2.0 |
10 |
40x25x10 |
| 2.0~8.0 |
2PD2080S |
1.25 |
1.20 |
0.5 |
20 |
0.2 |
2.0 |
10 |
40x25x10 |
| 2.0~10.0 |
2PD20100S |
1.25 |
1.20 |
0.5 |
22 |
0.2 |
2.0 |
10 |
40x25x10 |
| 2.0~18.0 |
2PD20180S |
1.45 |
1.40 |
0.9 |
20 |
0.2 |
0.7 |
10 |
40x25x10 |
| 4.0~8.0 |
2PD4080S |
1.25 |
1.20 |
0.6 |
21 |
0.2 |
2.0 |
10 |
40x25x10 |
| 6.0~18.0 |
2PD60180S |
1.30 |
1.25 |
0.7 |
19 |
0.2 |
2.0 |
10 |
40x25x10 |
| 0.8~1.5 |
3PD0815S |
1.30 |
1.25 |
0.4 |
22 |
0.3 |
1.5 |
10 |
65x45x10 |
| 0.8~2.2 |
3PD0822S |
1.30 |
1.25 |
0.5 |
22 |
0.5 |
1.5 |
10 |
65x45x10 |
| 1.0~2.0 |
3PD1020S |
1.25 |
1.20 |
0.4 |
22 |
0.2 |
1.0 |
10 |
65x45x10 |
| 2.0~4.0 |
3PD2040S |
1.30 |
1.30 |
0.6 |
20 |
0.5 |
1.5 |
10 |
65x45x10 |
| 0.5~2.0 |
4PD0520S |
1.20 |
1.15 |
0.8 |
22 |
0.3 |
2.0 |
10 |
90x62x10 |
| 0.5~12.0 |
4PD05120S |
1.85 |
1.80 |
1.7 |
19 |
0.5 |
2.0 |
10 |
90x62x10 |
| 0.5~18.0 |
4PD05180S |
1.95 |
1.90 |
1.8 |
20 |
0.5 |
3.0 |
10 |
90x62x10 |
| 0.8~1.0 |
4PD0810S |
1.20 |
1.20 |
0.2 |
25 |
0.2 |
3.0 |
10 |
90x62x10 |
| 0.8~2.0 |
4PD0820S |
1.45 |
1.40 |
0.9 |
22 |
0.5 |
3.0 |
10 |
90x62x10 |
| 1.0~2.0 |
4PD1020S |
1.35 |
1.30 |
0.8 |
23 |
1.0 |
2.0 |
10 |
90x62x10 |
| 1.8~2.0 |
4PD1820S |
1.20 |
1.15 |
0.2 |
24 |
0.5 |
2.0 |
10 |
38x50x10 |
| 2.0~4.0 |
4PD2040S |
1.35 |
1.30 |
0.7 |
23 |
1.0 |
3.0 |
10 |
38x50x10 |
| 2.0~18.0 |
4PD20180S |
1.85 |
1.80 |
1.8 |
22 |
0.1 |
2.0 |
10 |
38x50x10 |
| 1.0~1.5 |
6PD1015S |
1.25 |
1.25 |
1.25 |
18 |
0.4 |
5.0 |
10 |
40x75x10 |
| 1.5~2.0 |
6PD1520S |
1.25 |
1.25 |
1.3 |
18 |
0.5 |
5.0 |
10 |
40x75x10 |
| 0.8~2.0 |
8PD0820S |
1.25 |
1.20 |
1.2 |
20 |
0.2 |
5.0 |
10 |
55x95x10 |
| 2.0~4.0 |
8PD2040S |
1.25 |
1.20 |
1.1 |
20 |
0.2 |
5.0 |
10 |
40x95x10 |
| 2.0~8.0 |
8PD2080S |
1.30 |
1.20 |
1.3 |
20 |
0.2 |
5.0 |
10 |
40x80x10 |
| 1.0~1.5 |
12PD1015S |
1.30 |
1.20 |
1.2 |
20 |
0.3 |
5.0 |
10 |
55x125x10 |
| 1.5~2.0 |
12PD1520S |
1.30 |
1.20 |
1.5 |
20 |
0.3 |
6.0 |
10 |
40x125x10 |
| 0.8~2.0 |
16PD0820S |
1.25 |
1.20 |
1.4 |
20 |
0.3 |
5.0 |
10 |
55x165x10 |
| 2.0~4.0 |
16PD2040S |
1.25 |
1.20 |
1.4 |
20 |
0.3 |
5.0 |
10 |
40x155x10 |
| 2.0~8.0 |
16PD2080S |
1.25 |
1.20 |
1.4 |
20 |
0.3 |
5.0 |
10 |
40x155x10 |
|
